in Mechanical Engineering from Stanford University in 2007. degree from the Engineering Department, Cambridge University, in 2002, and the Ph.D. in Computer Engineering from The George Washington University, in 1998, the M.Phil. Hopcroft (hopcroft at mems dot stanford dot edu) has been working in IC and MEMS research since 1998. Some explanation of basic layout concepts is given in Chapter 1, but this tutorial is not a complete introduction to the topic of IC or MEMS design. LayoutEditor already includes extensive HTML-based documentation which is sufficient for an experienced designer who is learning a new tool. This document is a beginners tutorial that is intended to help a first-time user get started using LayoutEditor.
#Trigonometry layouteditor mac os
Furthermore, LayoutEditor is the only such tool that can be used on all three major operating systems (Linux, Mac OS X, and Windows).
Comparable commercial products, such as L-Edit or Cadence Virtuoso, typically cost $1000’s per user. Development began in 2004, and after three years, it has acheived an outstanding level of capability and features that make it suitable for everyday use with small to medium size projects.
The software was created by J˝urgen Thies (jurgenthies at juergenthies dot de) and is an open-source project, distributed under the General Public License (GPL). LayoutEditor is a software tool for creating designs for microfabrication, such as integrated circuits (IC) and micro-electro-mechanical systems (MEMS). On the cover: layout for a CMOS dual seven-segment LED driver designed by the author, displayed in LayoutEditor.
